A float switch is a liquid level detection device that controls the switch state through the position of the float. It is widely used in liquid container monitoring and automated control systems. Understanding the "Normally Open" (NO) and "Normally Closed" (NC) states of a float switch is essential for proper installation and operation. Here’s a detailed explanation:
1. Normally Open (NO)
• Definition: When the float is in a resting state (the liquid level has not reached the set point), the switch contacts are open (disconnected). When the liquid level rises or falls to the set point, the float triggers the switch to close (connect).
• Applications:
Normally open float switches are used in scenarios where an action is needed when the liquid level rises. For example:
o Activating a drain pump when the water level reaches the set point to prevent overflow.
o Triggering an alarm when the liquid level is too high.
2. Normally Closed (NC)
• Definition: When the float is in a resting state (the liquid level has not reached the set point), the switch contacts are closed (connected). When the liquid level rises or falls to the set point, the float triggers the switch to open (disconnect).
• Applications:
Normally closed float switches are used in scenarios where an action is needed when the liquid level falls. For example:
o Activating a water pump to refill the tank when the liquid level drops below the set point.
o Triggering an alarm when the liquid level is too low to prevent equipment damage from running dry.
3. Working Principle
Float switches typically rely on the interaction between a magnetic element inside the float and a reed switch. As the liquid level changes, the float's position moves the magnetic element, which then activates or deactivates the reed switch, achieving the normally open or normally closed state.
4. How to Choose?
• Based on Control Logic: Select the appropriate type based on whether the system requires actions to be triggered by a rising or falling liquid level.
• Adjustable Float Switches: Some float switches allow the installation direction to be adjusted, enabling them to function as either normally open or normally closed. Follow the product manual for correct installation.
5. Precautions
• Ensure the action point of the float switch matches the liquid level control requirements.
• Regularly inspect the float and switch for proper functioning to avoid issues caused by dirt or corrosion.
• Select a float switch material suitable for the liquid being monitored to prevent corrosion or damage.
By understanding and properly configuring the normally open and normally closed functions, float switches can effectively control liquid levels and ensure safe and efficient system operation.
